Bench Type Tri-axial System

Description:
Application:

Suitable to do soil mechanical in geotechnical laboratory or do teaching in university or colleges .

Stressed controlled model, used to measure strength and deform data in static load conditions for soil specimen with dia39.1mm *80mm height , do UU , CU , CD .

Previous : Microprocessor–Controlled Direct Shear Apparatus

Next : Consolidation Apparatus

Product Introduction

Model: TSZ Series Item Name : Bench Triaxial Test Machine

Detailed Description

It is suitable for measuring soil strength, deformation and pore water pressure. According to the drainage conditions,

it can be used for unconsolidated undrained test (U-U test), consolidated undrained test (C-U test) and consolidated drained test (C-D test).

STANDARD

ASTM D4767
ASTM D2850
ASTM D7181

Specification :

1. Specimen size: Φ39.1×80mm
2. Axial load:    10KN
3. Lift speed range : 0.003-1.000 mm/min
4. Max. Stroke: 35mm
5. Max. confining pressure: 1Mpa
6. Max. back pressure:   0.6Mpa
7. Pore water pressure:   0-2Mpa
8. Volume change range: 0-50ml
9. Min. division: 0.1ml
10. Axial displacement range: 0-30mm
